Pomegranate Peeling Machine

This machine can separate the peel of grapefruit, orange, pomegranate, lemon and orange from the fruit. Purely mechanical removal of sacs, diaphragms, seeds, etc. Stainless steel for main material and housing frame, Omron of Japan or Siemens of Germany for electronic components and PLC.

Machine Parameters:

Model: QP-101 Pomegranate Peeling Machine

Dimension: 2100*950*1800mm

Voltage: 220V/380V/customized

Power: 3kw.

Handling Capacity: 500-1000kg per time

Suitable Fruits: pomegranate, grapefruit, orange, lemon, tangerine, citrus, etc.

Machine Features:

※ This machine uses program control plus remote control, the main material and shell frame are made of stainless steel, and the electronic components and PLC are made of Japanese Omron or German Siemens.

※ It is mainly composed of frame, feeding inlet, roller screen, spiral roller shaft, seeds outlet, skin outlet, control box, PLC, touch screen and so on.

※ Through the principle of reverse rotation of the spiral roller and the roller screen, the raw materials to be separated are broken through the gap, the seeds are discharged from the screen, and the skins are discharged from the end of the roller screen.

※ During operation, click on the touch screen, set parameters, put the whole pomegranate into the machine, and the machine can automatically complete the separation of pomegranate skin and fruit seeds.

※ It can be worked with washing machine, dewatering machine, juicing machine and some other machines to be an automatic processing line.

Finished Product Display:
