The machine adopts high pressure water flow and bubble generating device to impact the surface of the material to be cleaned. The energy generated when the bubble breaks in contact with the material will have impact and scrub effect on the surface of the material and clean the material. The ultrasonic function is added to the machine, which is more suitable for removing the small insects that are not easy to be removed by bubbles.
Machine Parameters:
Model: JC-320 Bubble Type Vegetables and Fruits Washing Machine
Dimension: 2800*980*1310mm/customized
Voltage: 220V/380V/customized
Power: 6kw
Capacity: 300-500kgs per hour or customized
Machine Features:
※ The machine adopts water bath type bubble cleaning method. Through the billow effect produced by the bubble in the process of release, the material has an irregular turnover movement in the water, and the attachment on the surface is effectively separated by the movement of the material. The machine simulates the action of manual cleaning, and because the material is produced in the mixture of bubbles and water, it can effectively avoid the damage to the material and improve the work efficiency.
※ The principle of ultrasonic cleaning machine is that the high-frequency vibration signal emitted by the ultrasonic generator is converted into high-frequency mechanical vibration by the transducer and then propagated to the medium - cleaning solvent. Ultrasonic waves radiate forward in the cleaning liquid in a sparse and dense manner, causing the liquid to flow and generate tens of thousands of tiny bubbles with a diameter of 50-500μm. The tiny bubbles in the liquid vibrate under the action of the sound field. These bubbles are formed and grow in the negative pressure area of the longitudinal propagation of ultrasonic waves, and in the positive pressure area, when the sound pressure reaches a certain value, the bubbles increase rapidly, and then suddenly close, and generate shock waves when closing, generating thousands of atmospheres of pressure around them, destroying insoluble dirt and dispersing them in the cleaning liquid. When the group particles are wrapped in oil and adhere to the surface of the cleaning part, the oil is emulsified and the solid particles are separated, thereby achieving the purpose of cleaning.
※ The machine is equipped with circulating water filtration system, and the water in the tank is continuously filtered by the pump to achieve the purpose of purification. The sewage containing floating matter is discharged from the overflow port, and the dirt deposited on the bottom of the pool is discharged from the bottom of the machine.
※ By adjusting the universal nozzles, the discharge speed of the material can be adjusted. The strength of bubbles can be freely adjusted according to the softness and fragility of different vegetables. The material moves with the conveyor belt, the conveying is smooth, the speed is adjustable, and the damage to the conveying material can be avoided. Electrical appliances are waterproof to avoid burning due to wet environment.
※ It can be customized according to the requirements of different configurations such as conventional PP mesh belt, stainless steel mesh chain, stainless steel chain plate, etc., can also add ozone, brush, roller, spray, ultrasonic and other functions.
※ Most suitable for washing broccoli, waxberry, small cray, shell, etc.
