This continuous-type frequency conversion control centrifugal dehydrator uses a maximum of 1440rpm high-speed rotation to quickly dry the surface moisture of vegetables. The body is made of 304 stainless steel, and the PLC control panel can set the dehydration frequency and time, which is suitable for a variety of different materials, with stable operation and high degree of dehydration.
Machine Parameters:
Model: JC-380 Continuous Type Centrifugal Dehydrator Machine
Dimension of Dehydrator: 1590*1170*2030mm
Dimension of Conveyor Belt: 3500*1225*2160mm
Voltage: 220V/380V/customized
Power: 5.5kw
Rotating Speed: max. 1440rpm
Handling capacity: 500-1000kg/h
Machine Features:
※ The automatic continuous dehydrator uses the principle of centrifugation to dehydrate the materials and remove the water on the surface.
※ The machine is controlled by micro-computer PLC, which can set dewatering frequency and time independently according to different materials.
※ The feeding conveyor with double layers makes the feeding more uniform to obtain better dewatering efficiency.
※ The equipment adopts independent electric box, which can eliminate the vibration of the electric box and prevent the internal parts of the electric box from loosing.
Application Products:
